cc.db

The file at /var/local/cc.db is used by com.lab126.ccat and stores information regarding the indexed books and collections.

It contains the following tables:

BACKFILLING
Collation
Collections
CollectionsJournal
DBOK
Entries
Locale
Series
SharedStates
Versions

BACKFILLING

Unknown.

Column	Type	Description
x_version	BLOB (int)

Collation

Described as “current collation locale (string)”. Otherwise unknown.

Column	Type	Description
collation	BLOB

Collections

Table where the collections (user-created “series” grouping). This is a N-to-N mapping between a collection UUID and a collection member UUID.

The same data can potentially be found from the Entries table, it is unsure which one is the source of truth.

Column	Type	Description
i_collection_uuid	BLOB (UUID)	Collection side
i_member_uuid	BLOB (UUID)	Member side
i_order	BLOB (int)	Order of member within collection
i_member_cde_type	BLOB	cdeType of the member
i_member_cde_key	BLOB	cdeKey of the member
i_member_is_present	BLOB	member is present on device
i_is_sideloaded	BLOB	Item sideloaded/downloaded value

There is a UNIQUE (i_collection_uuid, i_member_uuid) constraint on this table.

CollectionsJournal

Unknown.

Column	Type	Description
i_event_time	BLOB (datetime)	Event time
j_event	BLOB (json)	Contains the collections event

DBOK

Unknown.

Column	Type	Description
x_ok	BLOB

The x_ok column is defined as:
PRIMARY KEY
NOT NULL
UNIQUE
CHECK (x_ok = 1)
CHECK (typeof(x_ok) = "integer")

Entries

Main table containing the whole catalog. Everything is here, including books, collections, series containers, dictionaries, and system entries.

The p_titles_0_collation and p_credits_0_name_collation columns use COLLATE icu, which requires the ICU extension. The Kindle’s com.lab126.ccat service has ICU built in, but the standalone sqlite3 CLI on the device does not. This means INSERT operations on this table will fail when using the sqlite3 CLI with Error: no such collation sequence: icu. Workarounds include registering a stub collation in Python (conn.create_collation("icu", ...)), or temporarily stripping COLLATE icu from the schema via PRAGMA writable_schema=ON.

Column	Type	Description
p_uuid	BLOB PRIMARY KEY NOT NULL (UUID)	ID of entry
p_type	BLOB (string)	App-defined type. Known values: `Entry:Item` (books), `Entry:Item:Series` (series container), `Entry:Item:Dictionary`, `Entry:Item:Audible`, `Entry:Item:Feedback`, `Entry:Item:ADC`, `Entry:Item:HDC`, `Entry:Item:Images`, `Entry:Item:AKUGC`, `Entry:Item:HKUGC`, `Collection`
p_location	BLOB (string)	Location (URI to content)
p_lastAccess	BLOB (datetime)	Last access
p_modificationTime	BLOB (datetime)	File modification
p_isArchived	BLOB (bool)	Is archived item?
p_titles_0_nominal	BLOB (string)	Pieces of first title (LString)
p_titles_0_collation	BLOB COLLATE icu (string)	Used only for filtering and sorting
p_titles_0_pronunciation	BLOB (string)	Return value is always j_titles
j_titles	BLOB (array of hashmap)	All titles (array of LString)
p_titleCount	BLOB (int)	How many titles (unsigned)
p_credits_0_name_collation	BLOB COLLATE icu (string)	Collation string for first credit
j_credits	BLOB (array of hashmap)	All credits
j_creditCount	BLOB (int)	How many credits (unsigned)
j_collections	BLOB (array of UUID)	This entry is a member of these collections
p_collectionCount	BLOB (int)	How many collections (used for filtering)
j_members	BLOB (array of UUID)	This collection has these members
p_memberCount	BLOB (int)	How many members (used for filtering)
p_lastAccessedPosition	BLOB	For books: LPR; MP3/Audio: last timestamp played
p_publicationDate	BLOB (UTC datetime)	Publication date (Whether this should be interpreted as a floating date or a timepoint depends on the content, and we have no reliable way of knowing which is which—currently, use type (EBook, Blog, Magazine, etc.) to decide
p_expirationDate	BLOB (UTC datetime)	Expiration date. (Time when this item should be purged. Typically used for periodicals and blogs. Will be null for books, etc. which should not be purged)
p_publisher	BLOB (string)	Publisher
p_isDRMProtected	BLOB (bool)	Has DRM?
p_isVisibleHome	BLOB (bool)	Should appear in Home?
p_isLatestItem	BLOB (bool)	Is this the latest item in a group such as a periodical?
p_isDownloading	BLOB (bool)	Is currently downloading?
p_isUpdateAvailable	BLOB (bool)	Is an update available, say to a KDK app?
p_virtualCollectionCount	BLOB (int)	Number of items in a virtual collection, such as Periodical Back Issues or Archived Items
p_languages_0	BLOB (string)	Primary content language
j_languages	BLOB (array of IETF BCP 47)	All content languages
p_languageCount	BLOB (int)	How many languages (unsigned)
p_mimeType	BLOB (string)	Mime type
p_cover	BLOB (string)	Cover location (URI)
p_thumbnail	BLOB (string)	Thumbnail location (URI)
p_diskUsage	BLOB (int)	Bytes on disk
p_cdeGroup	BLOB (string)	CDE Grouping ID (to group periodicals, Retail ASIN)
p_cdeKey	BLOB (string)	CDE Key/ASIN
p_cdeType	BLOB (string)	CDE Type. Known values: `EBOK` (Amazon ebook or sideloaded book), `PDOC` (personal document), `AUDI` (Audible audiobook), `series` (series container entry)
p_version	BLOB (string)	Content version
p_guid	BLOB (string)	Content GUID
j_displayObjects	BLOB (array of hashmap)	What to display
j_displayTags	BLOB (array of string)	Tags to display (array of enum (string) values)
j_excludedTransports	BLOB (array of string)	Disallowed networks for download
p_isMultimediaEnabled	BLOB (bool)	For Luna books
p_watermark	BLOB (string)	Watermark
p_contentSize	BLOB (int)	Human-perceived length
p_percentFinished	BLOB (float)	What percentage of the total content length the lastAccessedPosition represents
p_isTestData	BLOB (bool)	Is this test data?
p_contentIndexedState	BLOB (int)	The state of indexing the content of this entry
p_metadataIndexedState	BLOB (int)	The state of indexing the metadata of this entry
p_noteIndexedState	BLOB (int)	The state of indexing the notes/annotations of this entry
p_credits_0_name_pronunciation	BLOB (string)	Authors pronunciation
p_metadataStemWords	BLOB	Metadata stem words (not used currently. Introduced in J3)
p_metadataStemLanguage	BLOB	Language of the metadata (not used currently. Introduced in J3)
p_ownershipType	BLOB (int)	Ownership type
p_shareType	BLOB	Support share feature in Discovery App
p_contentState	BLOB (int)	Downloaded / sideloaded value
p_metadataUnicodeWords	BLOB (string)	Searchable metadata for contents. Terms are separated by U+FFFC (OBJECT REPLACEMENT CHARACTER). Typically contains the title and author name repeated: `title\ufffctitle\ufffcauthor\ufffcauthor`
p_homeMemberCount	BLOB (int)	Number of downloaded/sideloaded books inside a collection
j_collectionsSyncAttributes	BLOB	Collection sync attributes
p_collectionSyncCounter	BLOB (int)	Max whispersync counter for a collection
p_collectionDataSetName	BLOB (string)	Whispersync dataset name for collection
p_originType	BLOB (int)	Content Origin Type
p_pvcId	BLOB	PVC identifier
p_companionCdeKey	BLOB (string)	Companion CDE ASIN. For an audio book, we may have a companion ebook and vice-versa
p_seriesState	BLOB (int)	Series membership state. `0` = this entry is a member of a series (the firmware hides it from the main library and shows it inside the series container). `1` = default value for all other entries (books not in a series, dictionaries, collections, system items, and `Entry:Item:Series` container rows themselves)
p_totalContentSize	REAL (long)	Total size (including sidecars) occupied by the content on the device
p_visibilityState	BLOB (int)	Used to determine whether an entry should be visible or not
p_isProcessed	BLOB (int)	Flag to specify whether the entry should be processed or has already been processed
p_readState	BLOB (int)	Indicates the read state of an entry
p_subType	BLOB (int)	Integer to specify the sub type of the entry

Locale

Unknown.

Column	Type	Description
locale	BLOB (string)

Series

Maps books to series for the “Group Series in Library” feature (firmware 5.13.4+). For Amazon-purchased books, this table is populated by Amazon’s servers during metadata sync. It can also be populated manually for sideloaded books to achieve the same visual grouping.

Each row links a single book to a series. A series with 9 books has 9 rows, all sharing the same d_seriesId.

Column	Type	Description
d_seriesId	BLOB (string)	Series identifier. Format: `urn:collection:1:asin-{ASIN}` where `{ASIN}` is the Amazon series ASIN (e.g. `B08BX5D4LC`)
d_itemCdeKey	BLOB (string)	`p_cdeKey` of the member book from the Entries table
d_itemPosition	BLOB (double)	0-indexed position in the series (Book 1 = `0`, Book 2 = `1`, etc.)
d_itemPositionLabel	BLOB (string)	1-indexed display label shown in the UI (e.g. `"1"`, `"2"`)
d_itemType	BLOB (string)	Type of the member. Always `Entry:Item` for books
d_seriesOrderType	BLOB (string)	Sort behavior. Observed values: `ordered`, `unordered`

There is a UNIQUE (d_seriesId, d_itemCdeKey) constraint on this table.

Series grouping requirements

For a series to appear in the Kindle library, three things must exist in the database:

Rows in the Series table linking each book to the series (this table)
An Entry:Item:Series row in the Entries table acting as the series container (see below)
p_seriesState = 0 on each member book’s Entries row, which tells the firmware to hide the individual book and show it inside the series instead

Entry:Item:Series rows

Each series has a corresponding row in the Entries table with p_type = 'Entry:Item:Series'. This is the series container that appears in the library. Key fields:

Field	Value / Description
`p_type`	`Entry:Item:Series`
`p_cdeKey`	The series ASIN (matches the `{ASIN}` portion of `d_seriesId`)
`p_cdeType`	`series`
`p_cdeGroup`	Same as `d_seriesId`: `urn:collection:1:asin-{ASIN}`
`p_mimeType`	`application/x-kindle-series`
`j_titles`	JSON: `[{"display":"Series Name","collation":"Series Name","language":"en","pronunciation":"Series Name"}]`
`j_credits`	Copied from the first book’s author credits
`p_thumbnail`	Path to the first book’s cover (e.g. `/mnt/us/system/thumbnails/thumbnail_{cdeKey}_EBOK_portrait.jpg`)
`j_members`	`[]` (empty — membership is tracked via the `Series` table, not this field)
`p_memberCount`	Total number of books in the series
`p_homeMemberCount`	Number of downloaded/sideloaded books in the series on the device
`j_displayObjects`	`[{"ref":"titles"},{"ref":"credits"}]`
`p_isArchived`	`1`
`p_isVisibleInHome`	`1`
`p_seriesState`	`1` (the container itself uses `1`; member books use `0`)
`p_visibilityState`	`1`
`p_originType`	`-1`
`p_contentIndexedState`	`2147483647` (INT_MAX — not applicable for series containers)
`p_virtualCollectionCount`	`p_memberCount + 1`

Versions

Unknown.

Column	Type	Description
x_table	BLOB (string) PRIMARY KEY NOT NULL UNIQUE
x_version	BLOB (int)
